wheel Loader
Specifications
- Brand
- cnhtc
- Origin
- china
- Price Term
- FOB
wheel Loader is a Other Construction Machinery product. Key specs — Brand: cnhtc; Origin: china; Price Term: FOB.
Product Description
Standard configure
ENGINE
Model:C6121ZG10h(under CAT 3306B License)
Type: in-line,water cooled, dir.inject turbocharged, 4-stroke
Cylinder-bore*stroke:6-121*152mm
Rated power:158kw(210hp)
Min. fuel consuption:235g/kw.h
Max .torque:912N.m/1400-1500rpm
Rated speed:2200r/min
Min .consumtion:214g/kw.h
Lubrication:gear-pump, force-lubrication
Total displacement:10.5L
BRAKES
Service brake:Fully sealed wet disc type
Parking brake:air cutting control inner expand hoof
Emergency brake:air cutting control inner expand hoof
TRANSMISSION
Model :ZF4WG200
Torque converter:3-element,single stage
Type of transmission:coountershaft,powershift withKDswitch
Number of gear shift:4forward;3reverse
Max .travel speed:38 km/h
SERVICE REFILLING CAPACITIES
Fuel tank:300L
Engine lubrication(oil pan):21L
Coolant:60L
Hydraulic oil tank:300L
Front axle:34L
Rear axle:28L
Torque converter &gear box:30L
HYDRAULIC SYSTEM
Steering pump:gear pump
Working pump:gear pump
Type of distribution valve:PPC control
Liftingtime(at full load):6.5s
Dumping time:1.5s
Lowering (unload) time:2.0s
AXLES&TYRES
Model of axle:ZF AP409/411
Front axle:fixed to frame
Rear axle:oscillating to frame
Oscillating angle of frame:±12°
Tyre size:23.5-25 16PR(L-3)
STEERING SYSTEM
Type :articulated and hydraulic steering
Steering angle:38°±1°(each direction)
Min turning radius(outside of bucket):6630mm
DIMENTIONS
Wheel base:3200mm
Tread :2250mm
Overall dimensions(length*width*height):7920*3050*3400
OPERATION SPECIFICATION
