Loader

Loader Loader is a widely used in highway, railway, construction, utilities, ports, mines and other construction projects, earthwork construction machinery, mainly for the shovel of soil, sand, lime, coal and other bulk materials, but also of the ore, slightly hard soil such as a shovel digging operations.

Our loader now has F, K and G three series, more than a dozen types of products. Distortion products are coal type, rock type, plateau and can be adapted to a variety of steel type and other conditions, both the clamp, slide the fork, snow plow, grass etc. grasping for users to choose different deformation equipment used.

In 1999, we successfully developed China's first with a leading domestic and international level of the third generation of synchronous loader, a complete end-end loader totally dependent on imports of China's history, setting off a technological revolution in Chinese industry.

In recent years, internally and externally in the production loader, has made covering parts, transmissions and other components of a major breakthrough in quality, product sales continued to rise.

We are very service-oriented brand creation in the country throughout the service, spare parts outlets, professional services and depth of services to the forefront of the industry.

Item Unit Parameter Rated bucket capacity m3 4.5 Rated load kg 8000 The whole quality of work kg 28500 Maximum traction force kN 245 Max breakout force kN 260 Boom lifting time s 6 And three time s 10.8 Tire Model 29.5-25-22PR Overall dimensions mm 9300 × 3500 × 3770 Engine Model Cummins QSM11-C335 Type water-cooled 4-stroke Breathing turbocharged, air-cooled Number of cylinders 6 Bore Piston Displacement 10.8L Electronic full speed governor Power 250kW (335HP) Rated speed 2100rpm Direct injection fuel system Maximum torque 1647nm 1400rmp Lubrication gear pump lubrication system Filter full flow Air filter (double filter, dust and dust with instructions) dry Torque converter Type single-stage, dual-phase, three-component Transmission Type planetary gear Travel speed km / h Drive four-wheel drive Fixed front wheel, full floating Rear center pin support, full floating, 26 ° swing Spiral bevel gear reduction gear Ordinary differential gear gear Final drive planetary gear, a deceleration Hydraulic wet disc brake brake (four) Wet disc brake parking brake Either the emergency brake parking brake Hinged type, full hydraulic power steering Two-way 40 ° steering angle Minimum turning radius (wheel center to the outside meter) 6200mm Steering system Hydraulic gear pump Maximum flow 168ltr/min Pressure relief valve setting 19MPa Steering cylinder Double-acting piston type Cylinder number 2 Bore × stroke 115mm × 445mm Load Control Hydraulic gear pump Rated flow 294 +168 I / min Safety valve set pressure 20MPa Working cylinder Double-acting piston type Cylinder number - bore × stroke: Boom 2-180mm × 880mm Bucket 1-220mm × 590mm Single handle control valves Control position Boom lift, hold, drop, float After dumping the bucket, keep, uninstall Cylinder working hours Lift 6 seconds Uninstall 3.6 seconds Down (empty bucket) 1.2 seconds Cooling System 65L Fuel tank 420L Engine 33L Hydraulic System 340L Drive axle (each) 66L Transmission 64L
