ZL30F Wheel Loader with Deutz engine

Deutz TB226B Engine
3 Ton wheel loader, wheel loader

Specifications:
Rated Loading Weight: 3,000KG
Rated Bucket Capacity: 1.7CBM
Tread: 1,800MM
Wheel Base: 2,750MM

Max. Breakout Force: 120.6KN
Max. Drawing Force: 90KN

Lifting, Lowering, Dumping Time: 10S (Full Load)
Max. Dump Height: 2,950MM
Max. Dump Reach: 1,100MM
Min. Ground Clearance: 370MM
Min. Turning Radius: 5,700MM

Engine: Deutz TB226B Diesel Engine
Rated Power: 92KW
Engine Rated Speed: 2,600RPM
No. Of Gear Shift: 4 Forward and 2 Reverse
Max. Travel Speed: 36Km/h

Tire Size: 17.5-25
Front Tire Pressure: 343KPa
Rear Tire Pressure: 304KPa
Service Brake System: Air Assisted Oil Disc Tire Four Wheel Brake
Fuel Tank Capacity: 108L

Overall Dimension: 6,909 x 2,400 x 3,190MM
Operating Weight: 9,600KG
Conveyance: Qty/2 X 40'HQ FCL: 3 Units

Optional Engine: Weichai R6105G20
Engine Type: Inline, Water Cooled, Direct Injection, Four Strokes
Number Of Cylinder-Internal Diameter x Strokes: 6-105 x 115
Max. Torque: 432NM
Rated Power: 85KW
Min Fuel Consumption: 221G/KW.H
Engine Rated Speed: 2,600RPM

Payment & Shipping Terms:
Price: FOB USD 20,000~25,000 / Unit
Minimum Order Quantity: 1 Unit/Units
Port: Qingdao
Packaging Details: 1 unit per 40`HQ container, 3 units can be loaded into 2 containers
Delivery Time: 30 day(lead time)
Payment Terms: L/C,T/T
Supply Ability: 90 Unit/Units per Month at least
