TAIMES 3206S SOLVENT PRINTER
Listing ID#10174724
Model3206S
CategoryPrinting Machine
Printing Machine

TAIMES 3206S SOLVENT PRINTER

Specifications

Brand
Taimes
Origin
guangdong
Request Quote
Quick answer

TAIMES 3206S SOLVENT PRINTER is a Printing Machine product. Key specs — Brand: Taimes; Origin: guangdong.

Product Description

Product Model TAIMES 3206S SOLVENT PRINTER
Printhead SPT510-35PL
Number of Printhead 6 Heads
Maximum Print Width 3200mm
Output (m2/h) Print Mode Standard Output (m2 /h)
240x540dpi 3pass 48.19
240x720dpi 4pass 37.12
240x540dpi 6pass 25.63
360x540dpi 3pass 35.73
360x720dpi 4pass 26.80
360x540dpi 6pass 18.46
360x720dpi 8pass 14.04
Ink Type : Solvent Ink / ECO-Solvent Ink
Color : 6 Colors( C , M , Y , K , Lc , Lm )
Capacity : 5L Per Main Tank of Each Color
Ink Supply System : Low Ink Detector, Auto or Manual Ink Supply System
Media Width : 3300mm
Type : Vinyl,Flex,Polyester,Back-lit Film, Window Film,etc
Auto Media Feeding System Equipped ( Max. Media Weight 80kg )
Auto Cleaning System Positive Pressure Cleaning Anti-clogged Flash Function & Capping System
Pre-heating & Drying System Equipped
Clamp Equipped
Print Interface USB2.0
Printhead Height 2 to 4 mm Above Media Adjustable
RIP Software Maintop , UltraPrint , PhotoPrint , Topaz , Wasatch , Caldera
Input Power AC 220V ,50Hz/60Hz
Machine Dimension L4,300 x W800 x H1,160 mm Net Weight : 340Kg
Package Dimension L4,450 x W870 x H1,300 mm Gross Weight : 420Kg
Operation Environment Temperature: 20~28 oC Humidity: 40%~60%

TAIMES 3206S SOLVENT PRINTER Advance Technic:
* Original Japanese drop on demand piezo print head with steel plate protected, 510 active nozzles/print head, 71.8mm printing width.
* 6 color plus 720dpi makes unmatchable color and high resolution.
* The voltage of the print head, automatically adjustable to the temperature, prevents blockage caused by the change of temperature.
* The function of skipping white space is added to increase productivity.
* The adjustment of bi-direction, step and carriage moving speed can be made during printing.
* Edge feather function can blur the pass line and feather the pass edge.
* Delicately designed alloy-aluminum platform.
