CY47 Series Offset Printing Machine

Simple operation: Handle is with 3 gears, water supply, ink supply and pressing.
Accurate positioning: employed front scale stopped and side scale puller. Accurate registration.
water/ ink separated: Ink and water supply are separated and you may freely adjust water and ink supply quantity.
Double-sheet Prevention: Effectly inspect and take away double sheets or mutliple sheets without machine stop.
Electronic counting: You may accurately control printing quantity.
Printing plate: PS plate, zinc oxide or water based plate.
Stable performance: Highly accurate gears and high strenth cast iron walls.
Powder spray: With powder spraying devices and powder spray is synchronized with printing and so product not get dirty.
Central lubing: to insure key parts well lubed.
Electrical control: It employed PLC control with self diagnosis. Inverter for speed regulationn. Speed ranges from 2,000 to 8,000 rpm.

Technical parameters:

Model	CY47/NP/L/â… /â…¡
Max. sheet sizes	470x365(mm)
Max. print area	454x345(mm)
Biting blnk edge	8(mm)
Sheet weight	28-250(g/m2)
Code pieces	7/7 lines = 49 pcs (transverse) 5/8 lines = 40 pcs (longitudinal)
Plate printing sizes	roller type: 90x 345mm local head type: 30x40mm
Max. print speed	8000 s/h
Print plate sizes	470x380x0.15(mm)
rubber sizes	470x420x1.95(mm)
Feed pile	500mm
Dimensions	1960x900x1340(mm)
Main motor	1.1Kw / 220V
Air pump motor	0.55Kw
Net weight (abt.)	910(Kg)
