Non-woven Printing Machine
Specifications
- Brand
- creditmachine
- Origin
- China
- Price Term
- FOB
Non-woven Printing Machine is a Printing Machine product. Key specs — Brand: creditmachine; Origin: China; Price Term: FOB.
Product Description
The printing machine uses the photopolymer plate, is suitable for the printing on the non-woven fabrics, PE, polypropylene plastics, web, etc
Characteristics:
The device is featured at the simple operation, soft staring and accurate color register, anilox ink transmission. The reliable drying system combines with high-speed running up and automatic cutout. The device has 360-degree continuous adjustable longitudinal pattern matching design and accurate color register. The frequency conversion motor has the adjustment of speed for suiting the different printing speed. The feeding uses the magnetic powder clutch; the discharging uses the magnetic powder.
Model | SX_FM-41000 | SX_FM-41200 | SX_FM-41400 | SX_FM-41600 |
Max width of printing material | 1000mm | 1200mm | 1400mm | 1600mm |
Max width of printing | 960mm | 1160mm | 1360mm | 1560mm |
Length range of printing product | 200-800mm | 200-800mm | 200-800mm | 200-800mm |
Max diameter of rolled material | 1000mm | 1000mm | 1000mm | 1000mm |
Printing speed | 5-50m/min | 5-50m/min | 5-50m/min | 5-50m/min |
Thickness of printing plate | 3.94mm | 3.94mm | 3.94mm | 3.94mm |
Total power | 15kw | 17kw | 19kw | 21kw |
Weight | 1700kg | 1900kg | 2100kg | 2300kg |
Overall dimension (L*W*H) | 3.6*2.1*2.5m | 3.6*2.3*2.5m | 3.6*2.5*2.5m | 3.6*2.7*2.5m |
