Continuous Alkali Deweighting Machine

This machine is applicable to the continuous alkali deweighting of various polyester fabrics, offering improved apparent morphology and inherent property of polyester filament; and better flexibility, softness, drapability and anti-static property of the fiber. Furthermore, it can diminish the fabric pilling and improve hydrophilic and water absorption. Therefore, the finished fabric obtains its properties closer of woolen and real silk fabrics, such as soft hand touch, moderate stiffness, mild luster, desirable drapability, crease and shrink resistance, wash-and-wear, and easy washing.

The machine adopts latest technology and apparatuses, such as new-type, steamer adopts completed relaxation steaming transmitted by The crawler structural style surpasses the world’s advanced level with high strength and good air permeability. The whole machine takes on AC conversion synchronous speed control system, tension tower use pneumatic control, which can freely regulate the fabric tension. In particular, the steamer controls temperature accordant, with small temperature difference, large fabric holding capacity, and strictly control and display steaming time, showing advantages such as stable quality, high efficiency, easy operation, assistants and energy saving, excellent reproducibility, etc… hence an indispensable appliance for producing top-grade polyester silk-like.

Main technical parameters:

1.Machine width:1800mm,2000mm
fabric width:1600mm,1800mm
3. Fabric holding capacity: pre-steaming 25m;steaming 300m(max)
4.Operating rate:10-80m/min
source: steam
6.Steam pressure:0.4Mpa;consumotion:700kg/h(max)
7.Steam max temperature:110℃
8.Transmission mode:5-unit Ac motor conversion control synchronous speed
