Fabric Inspection Machine

Usage: This fabric inspection machine is suitable for inspecting and rolling up all kinds of cotton, knitted, woven, printed, and tricot fabrics etc.

Characteristics:

1.Photoelectric hydraulic edge-alignment system made in Taiwan is adopted. Power 1/2HP.

2.Fabric tension is adjustable via inverter, no shrink of fabric width.

3.Equipped with an expanding roller to eliminate curled edge. Expanding power 1/2HP

4.Speed of main motor is controlled by two inverters. Power 1/2HP.

5.Digital counter could make accurate measurement of length in yards or meters which can be interchanged.

6.Winding roller and feeding roller of this fabric inspection machine are driven by gear motor made in Taiwan. Power 1HP×2 sets.

7.Imported special foamed winding roller could roll up warp and weft knitted plush and short floss without sliding movement and untidy edge. Fabric rolls are neither too tight nor too loose.

Technical parameters:

1.Fabric width: 80”~144”.

2.Diameter of fabric rolls: ≦600mm.

3.Highest speed: 80m/min.

4.Power of main motor: 1HP×2 sets

5.Accuracy of alignment: ±3mm.
