Anti corrosion Tape

Product DescriptionThe T-100 series is Cold Applied Anti corrosion Tape for the Anti corrosion / Anticorrosion of underground, underwater, and overhead pipelines. The Adhesive of Anti corrosion Tape is a key in ground performance characteristic coupled with the low and high density polyethylene backing.

This kind of tape can be applied by hand or with a wrapping machine. Product Advantages: Conformable to irregular shapes. No release liner. Established in ground history.

Complies with AWWA (American Water Works Association) C-214 standard.Compatible with general coating systems.T-100 Inner Tape (Anti corrosion Tape) series Coating Systems with AWWA C-214 Standard: Thickness: (ASTM D 1000) Total mm mil mm mil mm mil mm mil mm mil mm mil 0.38 15 0.51 20 0.64 25 0.76 30 1.02 40 1.27 50 Film 0.25 10 0.30 12 0.33 13 0.38 15 0.51 20 0.64 25 Adhesive 0.13 5 0.21 8 0.31 12 0.38 15 0.51 20 0.63 25Tensile: 27 lbs/in 31 lbs/in 34 lbs/in 39 lbs/in 53 lbs/in 66 lbs/inLength: 60 Meter 50 Meter 40 Meter 30 Meter 25 Meter 20 MeterWidth: 2”, 3”, 4”, 6”, 9”,12”Colour: BlackComposition: Backing: low and high polyethylene & Adhesive: Butyl RubberElongation: 300%Peel Adhesion to Primed Pipe: (ASTM D 1000) 165 oz/in, 18N/10mmCathodic Disbandment: (ASTM G8) 0.25 in radius 6.4 mmWater Vapor Transmission Rate: (ASTM F1249) 0.2g/100in 2 /24h, 0.3mg/cm 2 /24hWater Absorption: (ASTM D570) ≤ 0.1Volume Resistively: (ASTM E257) 2.5 X 10 12 ohm mDielectric Strength: (ASTM D 149) 40 KVTemperature Range : ( Normal in Ground Service) -30 to 160 o F, -34 to 71 o CMore Product FeaturesHS Code: 39199090Trademark: nbIdealModel NO.: T-100Standard: AWWA C214 Standard or SY0414-98/SY0414-93Productivity: 6, 000, 000 Square Meter / yearUnit Price/Payment: USA2/Square MeterOrigin: P.

R. ChinaPacking: CartonMin. Order: 10, 000 Square MeterTransportation: By SeaBacking Paper (For Adhesive): PolyethyleneColor: Black, EtcSurface Material: PEEfficacy (For Tape): IndustryCompany: Ningbo Ideal Anticorrosion Material (Anticorrosion Tape)
