adhesive coating machine

Specifications: Installation power:220V/4800W Air pressure:0.3-0.5mpa pump type: Gear-pump Motor: Variable speed brushless AC speed:25KG/HR Viscosity:500-30000cps Capacity:5gallon Output volume:320cc/min Temperature control: touch-pad screen Range:20-220℃ Nozzle: swirl Swirl width: 10mm-80mm Action: coating close dot, line Dimension:80 x45 x93CM Weight:76kg Features: Used in the single product much volume fill glue, same save replace material time and waiting for the glue heating time, up production ratio Floor-standing design, moving convenience 20KG capacity deep rectangular PTFE coated tank.

25KG/HR melt rate, 300cc/min gear-pump rate. 3 zone temperature control over 7 ranges up to 220℃ Single hose outlet - standard hose length1.5m.

Power source 30 amp breaker 220/230V AC system Gear-pump for consistent, pulse-free repeatable dispensing Adopts internationally computer touch-pad control system to controls provide temperature settings of tank, hose, valve. Designed for low- to medium-viscosity dispensing up to 30,000 cps. Hose is Standard (7.5m) dual outlet cable.

Progressive heating and multiplayer filter. Effectively prevent the Impurities Into machine damage the pump gear With the function of high temperature protection function. Reduced material degradation, Optimum production output
