ADSL2+ Tester (DSL-3011A) is a Telecom Parts product. Key specs — Origin: DADI; Price Term: FOB.
Product Description
DSL-3011A ADSL Tester, a hand held light-weight tester that tests ADSL/ADSL2/ ADSL2+. An ideal tool for installation, maintenance, troubleshooting of the XDSL link.
:
xDSL physical layer test
oADSL2+module: completely support all present ADSL standards,include:ANSI T1.413 Issue 2, ITU-T G.992.1(G.dmt), ITU-T G.992.2 (G.lite), ITU-T G.992.3(ADSL2) , RE-ADSL2 and ITU-T G.992.5(ADSL2+).
oTest downstream rate, actual upstream rate, maximum rate and channel utilization rate of line
oTest index such as upstream noise margin, downstream noise margin,output power and power attenuation
oTest error code count value such as near end, far end FEC, CRC, HEC, NCD, OCD.
oTest automatically and display defect information such as proximal and remote signal loss, frame loss, power loss, cell loss, boundary loss, compare history with present.
oES statistics.
oDisplay bits per tone in graph and number
oDisplay SNR per tone in graph and figure.
oATM layer error test
xDSL network layer test
oSupport various upper layer protocol such as RFC1483 (RFC2684), PPPoE(RFC2516), DHCP, PAP/CHAP
oAcquire IP address and Ping test by PPPoE dial-up
oFixed Ping test
oPing test includes power loss test (define time, package size), Ping loopback delay test (max. min. average)
oCompletely replace ADSL2+ Modem
Ethernet test
oPing test
cable test
oDMM: loop resistance, insulation resistance, capacitance, AC and DC voltage and line length estimation test
oTone generator
others
oauto power-off
osound, LED alarming instruction
odata management
osoftware on-line upgrading
:
1.TFT true color display, touch screen operation
2.UcOS operation system, graphical interface, easy to operate
3.Line qualified/unqualified indicator function: parameter threshold value of user-defined key line, judge whether the line is qualified through comparing actual test results with threshold value
4.Audio line-tracking: at one end of the line sends audio line-tracking signal, the other end identifies present tested line through audio sensor
