vacuum pump
Specifications
- Brand
- Kuvid
- Origin
- China (Mainland)
vacuum pump is a Vehicle Parts & Accessories product. Key specs — Brand: Kuvid; Origin: China (Mainland).
Product Description
The vacuum pump provides proper amount of vacuum to the brake booster of electric vehicles. The electric vacuum pump is the first one suitable for varies of electric vehicles and hybrid-electric vehicles in China.
With the lubricating oil free, higher exhaust speed, long service time, low power and so type HDZKB-F1 has low noise and vibration levels, hardly noticed when it engages.
The vacuum is controlled by a pressure Electrical CharacteristicsModel HDZKB-F1 72V Power 50WVoltage 72VDC Flow Rate 35L/minSize 200×160×160mm Net Weight 2.5kgNoise < 60 db Gross Weight 2.6kgMaximum Vacuum -0.08MPa PressureControl ON:-0.045MPaOFF:-0.065MPa±0.005MPa
