Listing ID#10212570
ModelD2
CategoryIron & Iron Products
Quick answer
tool steel is a Iron & Iron Products product. Key specs — Origin: China; Price Term: CIF.
Product Description
| No. | Corresponding Materials | ||||||||||
| AISI | GS | ASSAB | JIS | DAIDO | |||||||
| Cr12Mo1V1 | D2 | 1.2379 | XW-41 | SKD11 | DC-11 | ||||||
| Chemical Rate Analysis |
| Si | Mn | Cr | Mo | V | P | S | Ni | Cu | |
| ≤ | |||||||||||
| 1.40 | ≤0.6 | ≤0.6 | 11.00 | 0.70 | 0.50 | 0.03 | 0.03 | 0.25 | 0.30 | ||
| ~ | ~ | ~ | ~ | ||||||||
| 1.60 | 13.00 | 1.20 | 1.10 | ||||||||
| Size | Round (Diameter:inch) | Flat (L<160″) | |||||||||
| Rolled | forged | 1/2"≤T≤4″ 4"≤W≤24″ | |||||||||
| 1/2"-2" | 2"-12" | ||||||||||
| Property &Applicant | Recognized for its high resistance against wear, high compression stregth and fine robustness .the spheroical annealed process make it easy process by shearing and cutting with no worry about crack during process.Applied in thickness no less than 2mm punch mould , all kind of small mould for shearing and cutter together with screw-rolled or slappered mould as well as some other forming mould like rulers . | ||||||||||
