tailgate platform is a Truck Parts product. Key specs — Brand: ambition; Origin: china.
Product Description
tailgate platform :
1.Lifing capacity:1ton,1.5ton,2ton,3ton.
2. Powerpack:Haldex brand
3.Power supply: 12V/160AH,24V/120AH
tailgate platform:
1.Hydraulic power unit : Haldex brand(imported from Sweden).Hydraulic power unit include gear pump,fuel tank,motor,sealing and so on.
2. Actual dimension: will be decided by customer actual drawing and specification.
3. Board type:anti-skid steel plate.
4.Balance cylinder: can adjust the tailgate to be horizontal once started and no need to adjust by operation. Also it can sway the tailgate by certain degree to keep the tailgate unparalelled with the truck to prevent the goods from slipping off when the truck stay on a slope.
5.Accessory:two rubber bumper, one hand wire control,two mounting plates,two safety chains.
6.Valve: there are 5 valves:check valve, relief valve,overflow valve,flow-control valve, reversing valve.
7.Hydraulic components:
seal: Hallite brand imported from U.K
pipe: Semperite brand imported from Europe
C.powerpack: Haldex brand imported from Sweden
8.Installation and troubleshooting manual:available. It will advise you ,in a very simple way, how to install and analyze and remove the failure. Even a non-professional people will know how to use and repair it under our guidance.
testing: we conduct full-loading testing before each shipment .
