spot light is a Lights & Lighting product. Key specs — Origin: CHINA; Price Term: FOB.
Product Description
·Low power consumption.
·Good color rendering.
·Shock resistance.
spot light Applications
Hotels, restaurants, showrooms, KTV, shopping mall, retail shop
Show case, cabinet
spot light Features
Dimension: φ122*120mm
Power Consumption:9w
Color Temp: Cool white/Warm white
System Efficiency:100Lm/W
Input Voltage:100-250V
LED Life Span: 50,000Hrs
Safety Cert:CE,ROHS
spot light Code
ws-901-0-AE27
high power spotlight Technical Specification
high power spotlight Electrical Characteristiic
Parameter | Symbol | Min. | Typ. | Max. | Unit | Remark |
Power Consumption Input Current Input Voltage Operating Temperature Storage Temperature | P I V Top Tst | - - - -20 -30 | 9 320 100-250 28 25 | - - - 80 60 | W mA Vdc °C °C |
high power spotlight Photometric Characteristic
Parameter | Symbol | Min. | Typ. | Max. | Unit | Remark |
Luminious Flux Color Temperature CRI | Lm CCT - | 810 2500 - | 900 3000 80 | 990 8000 - | Lm K Ra |
