Product Description

The Fang Xing Solar roofThe FangXing slate solar roof is the China's first fully integratedsolar system using slate roof tiles. The system has beendesigned to seamlessly incorporate FangXing Solartiles with FangXing Slate roof tiles without the need for flashings or any adjustment in battens.Solar Roof Technical DataMinimum roof pitch 19°

Batten spacing 340mm

Size of Tile 940mm x 410mm900mm x 350mm exposed

Weight as laid 19.04kg per m2

Weight per tile 6kg

Power per tile 30Wp

Output/m2 95.23Wp

Prime working voltage (V).- Vmp 6.14 V

Prime working current (A).- Imp 4.886 A

Open circuit voltage (V).- Voc 7.4 V

Short circuit current (A).- Isc 5.3 A
