Listing ID#10211953
ModelCADE-S600
CategoryOther Farm Machines
shoe mould making machinery
Specifications
- Brand
- CADE
- Origin
- CHINA
Quick answer
shoe mould making machinery is a Other Farm Machines product. Key specs — Brand: CADE; Origin: CHINA.
Product Description
The high rigidity, may process the aluminum mold, the iron mold.
The shoes mold unit clamp, the high accuracy,
The shoes mold unit clamp, the high accuracy,
Shoe mould making machine specification:
Paramter | Specification |
Accuracy | 0.001mm |
Repeatability Accuracy | 0.005mm |
Rpm (Max.) | 24000rpm |
Principal Axis Power | 4kw-5.5kw |
Feed Rate (Max.) | 8m/min |
Drive System | Panasonic |
Tool Collet (Max.) | Φ16(ER25) |
Machining Area (X) | 500mm |
Machining Area (Y) | 600mm |
Machining Area (Z) | 300mm |
Machine Size | 1550mm×2500mm×1850mm |
Machine Weight | 3500kg |
