pvc ceiling tiles

Model number :8820Sizes and specification: 595*595*7.5/8/9/10mm 603*603*7.5/8/9/10mm 605*605*7.5/8/9/10mm Advantages of Gypsum Board 1. The Gypsum Board is light-weighted , natural , environmental , moisture-proof , water and fire-resistance 2.

Be widely used in shopping centres , hospitals and public places for perfect ceiling decoration 3.Each size has its special designs , the length and design can be made according to the customers requirements 4.Be made of Pure Gypsum Powder and Fibre with strong function Certificates ISO certification and import-export license,ASTM A.

Specifications(mm): Length x Width: 595X595,595X1195,600X600,603X603, 605X605,603X1212, 610X1220(2′X4′) Thickness: 7.0,7.5, 8.0,8.5,9.0,9.5,12,12.5 Specifications Tolerance Length: +_ 1.0mm, Width : +_ 1.0mm , Thickness : +_ 0.5mm Packing: 6/8/10 pieces per carton with shrink wrap bag and importer trade mark printed on the carton strip.

Max loaded details :740/1350/1400 cartons, 3239.40-4032 squre meters, 23.5 Tons , loaded in one 20′FCL B. Technical Data :1.Weight / sqm: 7.0 mm: 5.5KGS. 7.5mm: 5.7KGS.8.0mm:5.9KGS.

8.5mm:6.2KGS.9.0mm:6.8KGS.9.5mm:7.1KGS.12mm:9.2KGS.12.5mm:9.5KGS resistant property No- flammable B1 in accordance with Chinese Standard GB8624-1997 3.Lengthways & Lateral Ruptures Load 7mm: >110N. 8.0mm : > 120N . 9.0mm: >140 N. Installation Match with Top quality T-32/38 grids with 0.30-0.45mm thickness.

C.Properties:The top quality pvc laminated gypsum ceiling tile with best aluminum foil backing is of thermal insulation, fire resistant, moisture resistant, no deviation, elegant, economic, environmental and easy installation, as the suspended ceiling tile and dry wall partition. A.

Environmental, effective resisting dust,conform to the standard of GB6566-2001(Building material radioactive nuclide ration) B. Moisture resistant, slight deviation,easy to clean, moisture rate ≤2%,conform to the national standard JC/T997-2006 (Decorative gypsum board with paper-facing) C.

Fire resistant A grade, conform to the Item 204 of BG50222-95 of (Building material inter decoration design fireproof criterion) D. Noise reduction Coefficient: 0.1-0.3 E. Thermal conductivity: 0.16W/MK F. Light reflectance :0.75 G. Humidity resistant: 95% Humidity & standing water. Mobile:86-13792960510
