Listing ID#10137883
ModelW308479
CategoryPressure Switches
pressure transmitter
Specifications
- Brand
- Midwest Group
- Origin
- China
Quick answer
pressure transmitter is a Pressure Switches product. Key specs — Brand: Midwest Group; Origin: China.
Product Description
pressure transmitter
W308479
W308479
Technical parameters:
Measuring range:-100KPa ~ 60MPa
temperature allowed:medium temperature: -30 ~ 85 ℃
Ambient temperature: -30 ~ 85 ℃
Storage temperature: -30 ~ 85 ℃
Relative Humidity: 0 ~ 95%.
Damping: 0.5S.
Temperature: TK <± 0.02% FS / K
Accuracy levels: 0.1,0.2,0.5 class
Operating voltage: 18 ~ 36VDC, standard +24 VDC
Output signal: 4 ~ 20mA (second-line system); 1 ~ 5V (three-wire system)
Load resistance: ≤1000Ω
Weight: 0.85 kg
