Listing ID#10143308
CategoryIndustrial Fabric
Quick answer
polypropylene filter is a Industrial Fabric product. Key specs — Origin: China (Mainland).
Product Description
| Filter pore size (microns) Performance indicators | 1 | 5 | 10 | 25 | 50 | 75 | 100 | 200 | |
| Weight(g/㎡) | 550 | 400 | 400 | 400 | 400 | 320 | 350 | 400 | |
| Thickness(mm) | 3.5 | 2.5 | 2.2 | 3 | 3.5 | 3.5 | 3.8 | 3.8 | |
| Air permeability (L/㎡/S) | 150 | 300 | 360 | 500 | 1000 | 2000 | 1500 | 1500 | |
| Tensile strength (N/5×20cm) | Warp | 1000 | 500 | 500 | 500 | 500 | 500 | 500 | 500 |
| Weft | 1500 | 1000 | 1000 | 1000 | 700 | 600 | 500 | 700 | |
| Tensile elongation(%) | Warp | 50 | 60 | 80 | 85 | 90 | 100 | 100 | 105 |
| Weft | 50 | 60 | 80 | 85 | 90 | 80 | 100 | 90 | |
