pipe bending machine
Specifications
- Origin
- China
- Packaging
- 800x80x80
- Price Term
- EX-Work
- Payment Term
- T/T
pipe bending machine is a Hydraulic Tools product. Key specs — Origin: China; Packaging: 800x80x80; Price Term: EX-Work; Payment Term: T/T.
Product Description
　　　　　　　　Manual Hydraulic Pipe Bending Machine This machine is applicable for bending pipes. It adopts manual hydraulic device , can bend different size pipes along with changing different moulds. It is very helpful for gas, construction and water system.
Model: SWG-4D Max Pressure: 62Mpa Max Movement: 420mm Angle Of Curve Tube: âˆ/2≤α≤∠Curvature Radius:4D Hydraulic Oil: N15 Pipe External Diameter Series D X T (mm): 21.3X2.75 26.7X2.75 33.5X3.25 42X3.25 48X3.5 60X3.5 75.5X3.75 88.5X4.0 108X4.5 Mould: 1/2", 3/4", 1", 1 1/4", 1 1/2", 2", 2 1/2", 3", 4" Gross Weight: 200 Kg Packing�Size:�1250*500*300(mm)
