optic fiber connector

Product note:

MTRJ fiber optic connectorand MTRJ fiber products include theadapter and various cable assemblies are one of the most commonly used products in market. MTRJ features the 2-fiber, dual connection and single ferrule design. MTRJ inherit the RJ style snag-free latch design.

MTRJ fiber connectors and products include the single mode types and multimode types, MTRJ use a plastic ferrule instead of ceramic, and there are no APC MTRJ connectors. There are female MTRJ and male MTRJ types, the difference is male type are with two pins in the connector. MTRJ fiber optic connector is used in density connections and it is born to use with duplex cables.

Our MTRJ fiber optic connectors and related MTRJ fiber products are made strictly according to the standards IEC 61754-18 and TIA/EIA 604-12. They are fully compatible with the equipment and devices from other suppliers and fit to use in LAN and FTTx applications.

MTRJ Fiber Optic Connector Features:

♦ FTTH, LAN, PON & Optical CATV
♦ Local ring net
♦ Optical fiber communication system
♦ Optical fiber test equipment
♦ Optical fiber sensor

AVAILABILITY

-The connector can be supplied as a pre-assembled one-piece connector or as connector kits.
-Clips are available for SC and LC duplex connectors

Housing kits without ferrule are available.
-PC and APC are available

FEATURE

Low insertion loss and back reflection loss

Free-floating ceramic ferrule

UL-rated plastic housing and boot

Boots in a variety of colors
High precision alignment

SPECIFICATIONS

Insertion Loss: Single mode l≤0.20dB & Multimode ≤0.25dB

Return Loss: PC ≥50 dB, UPC ≥55 Db & APC ≥65 dB

Durability <0.20 dB typical change, 1000 mating

Operating Temperature: -40 to + 80°C

Ferrule Hole Sizes:
Single mode: 125.0
