open diesel generator set

GF SERIES OF DIESEL GENERATING SETS FEATURES:All diesel generating sets include diesel engine,alternator and control box Starting method of gensets1)Manual switcher 2)Automatic starting whollywhen electric supply has been stopped,the gensets can start three times automatically in3-28 seconds(time can be adjustable)between electric supply and gensets need 6-8 will spend 12 seconds to accept load when electric supply resumed,geneset will maintain 20-230 seconds,then closed automatically down the3)Control systemappratus:voltmeter,frepuency meter,amperage meter,voltmeter of battery,meter of water meter,control section:stasrting/halt,ket type switch,Inductive type self-protection switch,and indicator lamp.

Technical Data MODEL ALTERNATOR DIESEL ENGINE GENSETS RATED OUTRUT RATED VOLTAGE(V) RATED CURRENT(A) FREQUENCY (Hz) POWER FACTOR MODEL DIMENSION L×M×H(CM) NET WEIGHT GF-8KW 8KW 400 14.4 50/60 0.8 295AD(20HP) 137×59×90 430kg GF-10KW 10KW 18.1 50/60 0.8 295AD(20HP) 142×59×90 460kg GF-12KW 12KW 21.7 50/60 0.8 295AD(20HP) 142×59×90 478kg GF-15KW 15KW 27.1 50/60 0.8 395AD(30HP) 158×61×97 600kg GF-20KW 20KW 36.1 50/60 0.8 495AD(38HP) 165×62×144 700kg GF-24KW 24KW 43.3 50/60 0.8 495AD(38HP) 165×62×144 707kg GF-30KW 30KW 54.1 50/60 0.8 495AZD(48HP) 180×62×120 835kg GF-40KW 40KW 72.2 50/60 0.8 4100ZD(56HP) 185×75×128 965kg GF-50KW 50KW 90.2 50/60 0.8 4105ZD(75HP) 190×75×128 1025kg GF-64KW 64KW 115.4 50/60 0.8 4135D 240×85×140 1800kg GF-75KW 75KW 135.3 50/60 0.8 6135 240×85×140 2330kg GF-90KW 90KW 162.3 50/60 0.8 6135D 300×90×137 2500kg GF-100KW 100KW 180.3 50/60 0.8 6135AD 300×90×137 2650kg GF-120KW 120KW 216.3 50/60 0.8 6135AZD 300×90×137 2800kg GF-150KW 150KW 270.3 50/60 0.8 12V135D 330×96×165 3500kg GF-200KW 200KW 360.8 50/60 0.8 812V135AD 321×132×192 3750kg GF-250KW 250KW 451 50/60 0.8 12V135D 321×132×192 3850kg GF-300KW 300KW 541.2 50/60 0.8 W12V135AZD-1 330×177×190.5 4300kg 1,Voltage steady-regulation ±% fluctuation ratio 1.5%Transient-state regulation -15-20% stead time 5sFrepuency steady-state regulation 5% fluctuation ratio 1.5%Remarks:the diesel engine have been made ±10% stead time 5sin china Transient-state regulation2,The noise of gensets should no more than 85ab(a)
