membrane switch
Specifications
- Brand
- OEM
- Origin
- Zhejiang,China
- Price Term
- FOB
membrane switch is a Business Services product. Key specs — Brand: OEM; Origin: Zhejiang,China; Price Term: FOB.
Product Description
1.membrane switch panel dome membrane switch membrane switch 4. with LCD window surface finish
membrane switch panel Overlay Materials: The most commonly used base materials are polyester and polycarbonate. Rear Adhesive: 3M 467MP, 3M 468MP, etc. Standard Tolerances: .010 inch. Matching color: Pantone and RAL color matching system. Environmental ·Storage Temperature: -40°C (-40°F) to +70°C (158°F). ·Storage Altitude: Sea level to 35,000 feet.
Performance Electrical Operating Voltage: 0-35 V DC. Operating Current: 100 MA Max. Operating Contact Resistance: Less than 100 OHMS typical Contact Bounce: Less than 5 Milliseconds typical. Conductors: Printed silver conductive inks or carbon blend. RFI and ESD Shielding: Available in most configurations.
Mechanical Life Expectancy: 1,000,000 actuations per switch position Actuation Force: 6-24 ounces, Range depending on customer specification. Switch Travel: .005" to .030" typical. Overall Thickness: .020" to .050" typical. Environmental Storage Temperature: -40°C (-40°F) to +70°C (158°F). Storage Altitude: Sea level to 35,000 feet.
Operating Temperature and Altitude: -30°C (-30°F) to +75°C (170°F). Can be designed to operate in most environments. Humidity: No delamination after 24 hours at 80°C and 90%RH.
