laser cutting machine sf1290
Specifications
- Origin
- China
- Price Term
- FOB
laser cutting machine sf1290 is a Business Services product. Key specs — Origin: China; Price Term: FOB.
Product Description
1.honeycomb platform
2.laser tube:CO2
up and down worktable
CE certificate
Model | SF-1290 |
Processing area | 1200*900mm |
Laser tube | 60W-120W |
Engraving speed | 1-60000mm/min |
Cutting speed | 1-10000mm/min |
Cutting thickness | 1-20mm Plexiglass(others determined by the material ) |
Minimum shaping character | Chinese :2*2mm; letter: 1*1mm |
Support graphic format | DST, PLT, BMP , DXF |
Resolution ratio | <0.01mm |
Location precision | <0.01mm |
Power supply | 220V/50HZ |
Operating temperature | 5 – 40 centigrade degrees |
Operating humidity | 5%-95% Free of condensed water |
Interface | USB |
Specification | CE |
G.W. | 300kg |
Gross power | 1500W-1800W |
Information
SF1290 laser engraving and cutting machine is a new laser equipment developed`specially by according to the needs of the market. Avoid waste the materials. It has the high beam of light, cutting without contact, avoid destroy, the kerf is narrow, the incision is smooth, the cutting force is strong, the cutting speed is high, the working efficiency is high.
Characteristics
ï¬The imported beeline lead rail, imported stepper engine with the lower speed running structure, the cutting is very stable, the cutting face is smooth.
ï¬High intention, high precision mechanic structure design, the data control is stable.
ï¬Choose high technical laser tube, the beam of light is of high quality and the life is long.
ï¬Input the American imported focusing lens and mental condensing lens, the cutting strength is high.
ï¬Co figurate the industrial water cooling system with protection, the continuum work ability is stable.
ï¬The compatibility of the software is good, which can support the format of PLT, BMP, DXF etc.
Applicable materials
Non-metal materials such as double color board, Plexiglas
glass, bamboo and wood, rubber, marble, granite and tiles, leather
Applicable industry
Billboards, artistic gifts, crystal ornaments, paper-cut, bamboo
and wooden product, garment and leather, embroidery, decoration and upholster industry.
