Listing ID#10096147
ModelRG56 series
CategoryOther Plastic & Rubber Machinery
heavy duty granulator
Specifications
- Brand
- RHONG
- Origin
- china
- Price Term
- FOB
Quick answer
heavy duty granulator is a Other Plastic & Rubber Machinery product. Key specs — Brand: RHONG; Origin: china; Price Term: FOB.
Product Description
RG56 series Heavy-duty Granulators are used to grind centralizedly thick remnants of pipes, moldings, and planking, package material, containers, sheet materials, wires, cables and so on. They play an important role in recylcing plastic wastes, defective goods and rejects and therefore can increase the utilization ratio of plastic material.
Features:
1.Integral body,sturdy and durable,keep excellent performance after using long time.
2.Heavy loading bearing and dust protection device,the sound-proof bunker can prevent vibration and noise effectively
overloading protector on the motor and interlock protection device on the power source,double protection for the safety of human being and motor.
4.Special cutter design adopting shear principle,made of high-chrominum shred,work together with high-speed motor,shred various plastics wastes easily.
gap between knives is knives can be dismounted when usharp,to be used repeatedly,long time working life.
6.Separable design,the bunker,main body,mesh frame are dismounted easily,convenient for bunker cleaning.
vibration feet,reduce the noise of vibration.
Please excuse for not note if some specification of products are changed.
Features:
1.Integral body,sturdy and durable,keep excellent performance after using long time.
2.Heavy loading bearing and dust protection device,the sound-proof bunker can prevent vibration and noise effectively
overloading protector on the motor and interlock protection device on the power source,double protection for the safety of human being and motor.
4.Special cutter design adopting shear principle,made of high-chrominum shred,work together with high-speed motor,shred various plastics wastes easily.
gap between knives is knives can be dismounted when usharp,to be used repeatedly,long time working life.
6.Separable design,the bunker,main body,mesh frame are dismounted easily,convenient for bunker cleaning.
vibration feet,reduce the noise of vibration.
Technical Specifications
| Model | Power(kw) | Diameter of rotation (mm) | Rotating Speed (r/min) | Rotating Blades | Fixed Blades | Screen hole (mm) | Cutting Chamber (mm) | Output (kg/h) | Noise dB(A) | Weight (kg) | Dust Separato (Including Evacuation blower) | |
| -A | * (Kw) | |||||||||||
| RG-5680 | 37 | 560 | 560 | 6 | 30 | 4 | Dia 12 | 660×800 | 1000-1600 | 110 | 3200 | 2.2 2.2 |
| RG-56100 | 55 | 560 | 560 | 6 | 39 | 4 | Dia 12 | 660×1000 | 1200-2000 | 110 | 4100 | 2.2 2.2 |
| RG-56120 | 75 | 560 | 560 | 6 | 4 | dia 12 | 660×1200 | 1500-2500 | 110 | 5100 | 2.2 2.2 | |
| External size | A | B | C | D | H |
| RG-5680 | 800 | 660 | 1820 | 2340 | 2810 |
| RG-56100 | 1000 | 660 | 2020 | 2340 | 2810 |
| RG-56120 | 1200 | 660 | 2190 | 2340 | 2810 |
Please excuse for not note if some specification of products are changed.
Note:
1) Staggered Blades(A),If without A,it means the paddle blades are used.
2) The max.Granulating quantity depend on the mesh hole diameterand material quality to be granulated.
3) The machine voltage specification is 3∮,380V,50Hz.
4) Blower(*)is selection purchase，if you want to equip with the blower on this series，the specification will be changed into RG-5680F,RG-56100F,RG-56120F.
