fully -automatic diamond wire mesh mavhine

Spider brand fully automatic chain link fence machine we produce is made with adaptation of Germany technology.

This machine offers high productive efficiency and reliable quality chain link fence products with reasonable design, using computer control, mechanical and electrical integration, automatic control of wire feeding, cutting, rolling and edge treatment.

Import advanced technology and domestic machinery prices make this machine an ideal choice for chain link fence producers. Main Technical Data: 1. Capacity: (square meter/hour) 25-60 2, Steel wire diameter: (mm) Φ2.0—Φ4.0. Wire feeding number: double wires.

Note: The steel wire meets the standard: GB3081-82 YB544-65 Steel Wire Material: B 1 F-B 3F 3, Chain link fence roll width: (mm) 600-2000, at any length 4, Power: electric motor: 3.0KW one set, 4.0KW one set, 0.12 KW one set
