envelope die cutting machine
Specifications
- Brand
- Hongtian
- Origin
- CHINA
- Price Term
- FOB
envelope die cutting machine is a Packaging Machines product. Key specs — Brand: Hongtian; Origin: CHINA; Price Term: FOB.
Product Description
Applications:cutting handbags, rubber& plastic products, leather products, stationery products , packing products , electronic packing, envelope and so on .
Features:
1. Two-tank, high precision, four-post structure, self-balance, connecting rod, these promise the equal pressure of each cutting depth.
2. Series B machine has super long stroke setting for the super thick material and super high die cutters.
3. When the cutting board press and touch the cutter , it has the auto slow cut, So that no size error between the uppermost layer and lowermost layer of the cutting material.
4. The special setting construction, work with the die cutter and cutting height, make stroke modulation simple and accurate.
5. Central automatic lubrication system ensures the precision and durability of the machine.
Model | JR-6A20T/48" | JR-6A20T/63" | JR-5B20T/48" | JR-5B20T/63" |
Cutting Force | 20 Tons | 20 Tons | 20 Tons | 20 Tons |
Dimension | 1800*1025*1180mm | 2060*1025*1180mm | 1800*1025*1180mm | 2060*1025*1180mm |
Cutting Area | 510*1220mm | 510*1600mm | 510*1220mm | 510*1600mm |
Motor | 2Hp | 2Hp | 2Hp | 2Hp |
Stroke | 55-165mm | 55-165mm | 55-245mm | 55-245mm |
Net Weight | 1600Kg | 1700Kg | 1700Kg | 1800Kg |
Our factory features,
1. Experience in cutting machinery over 20 years.
2. Outstanding components from Asia, such as Korean PLC computer,FUJI pump, Hongling motor.
3. Good after-sale service 1.5 year warranty. Offices in seven cities of China.
4. Costomerize.
5. Succeed in supplying the FOXCONN, the 109th in Top 500 Global corporations.
