double shuttle table injection molding machine
Specifications
- Origin
- shanghai
- Price Term
- FOB
double shuttle table injection molding machine is a Other Plastic & Rubber Machinery product. Key specs — Origin: shanghai; Price Term: FOB.
Product Description
Model HF-DM/600 | |||
Injection unite | Screw diameter | mm | 40 |
Shot volume | Cm 3 | 186 | |
Shot weight (PS) | g | 160 | |
Temperature section | Section | 3 | |
Injection pressure | Kg/cm2 | 1594 | |
Screw speed | Rpm | 0-175 | |
Clamping unite | Clamping force | KN | 600 |
Platen stroke | mm | 250 | |
Space between bars | mm | 500*340 | |
Mould plate size | mm | 650*490 | |
Max. mould thickness | mm | 380 | |
Min. mould thickness | mm | 130 | |
Ejector stroke distance | mm | 70 | |
Ejector stroke tonnage | KN | 12 | |
Others | Oil pump flux | L/Min | 47 |
Motor power | kw | 7.5 | |
Heating power | Kw | 4.2 | |
Machine weight | T | 2.95 | |
