Listing ID#10136606
ModelXL5135A
CategoryAuto Meter
Quick answer
digital ammeter is a Auto Meter product. Key specs — Origin: China (Mainland).
Product Description
Introducton:XL5135(AC220V) 3½ AC Power Supply Measuring DC Digital Ammeter
Tapping size(mm)：76×39.5
Dimension(mm)：W79×H42.5×D40
Install size：Inlay
| Model | Digitdisplay | Full measurement | Resolution | Accuracy | Input impedance | Max.input value | Power Supply | |
| XL5135A-1(AC2/DC) | 3½ | ±199.9µA | 100nA | ±1 % +3digit | 1KΩ | ±15mA | AC220V | |
| XL5135A-2(AC2/DC) | 3½ | ±1.999mA | 1µA | ±1 % +3digit | 100Ω | ±50mA | AC220V | |
| XL5135A-3(AC2/DC) | 3½ | ±19.99mA | 10µA | ±1 % +3digit | 10Ω | ±150mA | AC220V | |
| XL5135A-4(AC2/DC) | 3½ | ±199.9mA | 100µA | ±1 % +3digit | 1Ω | ±500mA | AC220V | |
| XL5135A-5(AC2/DC) | 3½ | ±1.999A | 1mA | ±1 % +3digit | 0.1Ω | ±3A | AC220V | |
| XL5135A-6(AC2/DC) | 3½ | ±5.00A | 10mA | ±1 % +3digit | 0.01Ω | ±6A | AC220V | |
