Listing ID#10043943
CategoryDiesel Generators
Quick answer
diesel generator set is a Diesel Generators product. Key specs — Brand: Eastpower; Origin: China.
Product Description
| Cummins Series Diesel Generator Set Specification | |||
| Model | EPC200S | ||
| Rated Voltage(V) | 400V/230V | ||
| Rated Frequency(Hz) | 50 | ||
| Standby Power(kW) | 176kW | 220kVA | |
| Rated Power(kW) | 160kW | 200kVA | |
| Rated CurrentRated/Standby | 288.6A/317.5A | ||
| Rated Power Factory(cosφ) | COSΦ=0.8 | ||
| Steady State Voltage Regulation% | ≤±1 | ||
| Voltage Adjust Range% | ≤±0.5 | ||
| Starting Control Mode | Manual/Automatic | ||
| Protection Function | Low Oil Pressure, High water temperature, Over Speed etc | ||
| Fuel Consumption | 205 g/kW·h | ||
| Noise LevelLP7m | 75dBA | ||
| Genset Dimensions(L*W*H)/mm | 3300×1300×1600 | ||
| Genset Weight | 3100kg | ||
| Cummins Engine: | |||
| Model | 6CTAA8.3-G2 | ||
| Nos of Cylinder | 6 | ||
| Bore*Stroke | 114×135 mm | ||
| Speed | 1500rpm | ||
| Compression Rate | 16.51 | ||
| Cylinder Structure | In-line | ||
| Starting Mode | DC24V Electric starting | ||
| Cooling Mode | Close water circulated cooling | ||
| Fuel Supply Mode | Vertical injection | ||
| Speed Governor Mode | Electric | ||
| Inspiration Mode | Turbocharged ,inter cooled, peripheral | ||
| Over load ability | 110% | ||
| Marathon Alternator: | |||
| Model | MP-160-4 | ||
| Rated Voltage | 400V/230V | ||
| Power Factor | COSΦ=0.8 | ||
| Insulation Class | H Class | ||
| Protection Class | IP21 | ||
| Connection Mode | 3 Phase 4 wires, Y-type connection | ||
| Voltage Control | AVR | ||
| Output Frequency | 50Hz | ||
