die heating furnace is a Business Services product. Key specs — Brand: YOUNGER; Origin: CHINA.
Product Description
Die heating furnace is to heat dies to let it go into extrusion machine
| item | die size | max. heating temperaure | heating time | total power | die QTY in each chamber | chamber QTY | furnace door open&close method | blower power |
| MJ-600-2 | 160*100 | 550 | 3-4 Hours | 18 | 6 | 2 | pheumatic | 1.1KW |
| MJ-800-2 | 180*140 | 550 | 3-4 Hours | 30 | 6 | 2 | 1.1KW | |
| MJ-1000-3 | 210*140 | 550 | 3-4 Hours | 63 | 6 | 3 | 1.1KW | |
| MJ-1250-3 | 220*140 | 550 | 3-4 Hours | 63 | 6 | 3 | 1.1KW | |
| MJ-1460-3 | 280*140 | 550 | 3-4 Hours | 72 | 4 | 3 | 1.5KW | |
| MJ-1650-4 | 320*160 | 550 | 3-4 Hours | 96 | 3 | 4 | 1.5KW | |
| MJ-1800-4 | 330*200 | 550 | 3-4 Hours | 108 | 3 | 4 | 1.5KW | |
| MJ-2000-4 | 420*200 | 550 | 3-4 Hours | 120 | 3 | 4 | 1.5KW | |
| MJ-2500-4 | 450*200 | 550 | 3-4 Hours | 144 | 3 | 4 | 1.5KW | |
| MJ-3300-4 | 550*500 | 550 | 3-4 Hours | 240 | 2 | 4 | 1.5KW |
