Listing ID#10152303
ModelZSW
CategoryFurniture Making Machines
crushing feeder
Specifications
- Brand
- Shanghai Jianye
- Origin
- China (Mainland)
Quick answer
crushing feeder is a Furniture Making Machines product. Key specs — Brand: Shanghai Jianye; Origin: China (Mainland).
Product Description
Vibrating Feeder Operating principle:
It makes the movable parts, such as sieve box and vibration device, to move compulsorily and successively just like a circle or a similar one, under the function of the centrifugal force occurred from the revolution of the eccentric block in the vibration device. The stuff moves with the continuous parabolic movement on the inclined screen surface, along with the sieve box. When thrown up, the materials are classified; when falling, they pass through the screen.
It makes the movable parts, such as sieve box and vibration device, to move compulsorily and successively just like a circle or a similar one, under the function of the centrifugal force occurred from the revolution of the eccentric block in the vibration device. The stuff moves with the continuous parabolic movement on the inclined screen surface, along with the sieve box. When thrown up, the materials are classified; when falling, they pass through the screen.
Vibrating Feeder Specification:
Model | Max Feed Size | Capacity | Speed of Eccentric Shaft(r/min) | Power | Electric Model | Overall Dimension | Weight |
GZD180×80 | 300 | 30-80 | - | 2×1.5 | 970 | 2200×1100×800 | 0.8 |
GZD300×90 | 500 | 40-100 | - | 2×2.2 | 970 | 3050×1430×1550 | 1.5 |
GZD370×100 | 700 | 150-300 | - | 2×3.2 | 970 | 4250×1874×1130 | 3.64 |
GZD430×120 | 800 | 200-400 | - | 2×5.5 | 970 | 4955×2206×1120 | 4.2 |
ZSW380×96 | 500 | 90-100 | 500-174 | 11 | 750 | 3882×2224×2121 | 3.98 |
ZSW490×96 | 500 | 120-240 | 500-800 | 15 | 1000 | 4957×2277×2150 | 5 |
