cross-sliding parking system
Listing ID#10038183
ModelDBJ-314
CategoryParking Equipment
Parking Equipment

cross-sliding parking system

Specifications

Origin
China (Mainland)
Price Term
FOB
Request Quote
Quick answer

cross-sliding parking system is a Parking Equipment product. Key specs — Origin: China (Mainland); Price Term: FOB.

Product Description

Parameters　　
　　　
Mode of driveHydraulicMotor
Size of car5000mm×1850mm×1550mm
Weight of car2000Kg
Lifting motor power3KW2.2KW
Lifting speed7-16m/min5.6m/min
Sliding motor power0.2KW
Sliding speed8m/min
ElectricityAC380V,50Hz,3phases 5 wires system
Safeguard devicesHydraulic whole protection and anti-fall frameAnti-fall frame (our patent)
Warning dexicesSound,light,electricity
Malfunction indicationFault diagnosis bu computer,liquid crystal display
Frame compositionColumns and beams are made of H type steel,Channel steel,angle steel and square pipes
Parts appearance treatmentGalvanized trestment and high-grade anti-corrosion paint
Mode of operationLCD /IC card/Manusl
ControllerPLC
Way of parking in and outForwarding, reversing into the spcae
