Listing ID#10048644
ModelPL-40HG
CategoryElectrical Equipment & Supplies
copper clad steel annealing machine
Specifications
- Brand
- poly
- Origin
- china
- Price Term
- FOB
Quick answer
copper clad steel annealing machine is a Electrical Equipment & Supplies product. Key specs — Brand: poly; Origin: china; Price Term: FOB.
Product Description
PL-40HG Copper-clad steel annealing Machine technical parameter
| machine type | 40HG | 32HG | 24HG |
| number of wire (mm) | 40 | 32 | 24 |
| finished wire diameter(mm) | ￠0.1-￠0.4 | ￠0.1-￠0.4 | ￠0.1-￠0.4 |
| tinning speed(MPM) | 120 | 120 | 120 |
| send-out method | hairbrush wire placing | ||
| annealing method | tubular annealing | ||
| mode of tin-plating | torque motor 1.2-1.8N.M 　 | ||
| annealing length(m) | 9 | 9 | 9 |
| spooler dimension(mm) | PT5-PT25 | PT5-PT25 | PT5-PT25 |
| installed thermal power(KW) | 73.2 | 73.2 | 73.22 |
| installed dynamic power(KW) | 11.8 | 10 | 9 |
| total installed power(KW) | 85 | 83.2 | 81.2 |
| traversing control | decelerate motor,loading & unloading unaided traversing | ||
| machine dimension(mm) | 22000L×2200W×2000H | 21000L×2200W×2000H | 20000L×1600W×2000H |
| machine weight(kg) | 4300 | 4100 | 4000 |
