Listing ID#10196060
ModelJF30
CategoryFurniture Making Machines
cap molding machine
Specifications
- Brand
- Jinfeng
- Origin
- China (mainland)
- Price Term
- FOB
Quick answer
cap molding machine is a Furniture Making Machines product. Key specs — Brand: Jinfeng; Origin: China (mainland); Price Term: FOB.
Product Description
Main technical parameters | |
Model | JF-30(16T) |
Number of die head | 16 cavities |
Productivity(pc/h) | 8000-11000pcs/h |
Total electrical power(KW) | 35KW |
Min cap diameter (mm) | 22mm |
Max cap diameter (mm) | 45mm |
Min cap height (mm) | 10mm |
Max cap height (mm) | 25mm |
Power supply | 380V, 50Hz |
Air distribution need (approximate) | 6kgs, 500NL/hr |
Weight (Kg) | 2500Kg |
Volume (L*W*H) | 2700×1150×2100mm |
Introduction | |
| |
| specification: | 　 | |||||||
| Type | 　 | 　 | 　 | 　 | JF-30(16T) | JF-30(24T) | ||
| Quantity of mold head | 　 | 　 | 16 | 　 | 24 | 　 | ||
| Capacity | 　 | 　 | 　 | 9000-11000pcs/hr | 15000-18000pcs/hr | |||
| Cap diameter | 　 | 　 | 　 | 22mm-45mm | 22mm-45mm | |||
| Cap height | 　 | 　 | 　 | 10mm-25mm | 10mm-25mm | |||
| Screwdiameter of the extruder | 　 | 50mm | 　 | 65mm | 　 | |||
| Power of heating ring of the extruder | 　 | 11KW | 　 | 11KW | 　 | |||
| Power of electromotor of the extruder | 　 | 4.5KW | 　 | 7.5KW | 　 | |||
| Power of electromotor of the molding press machine | 1.1KW | 　 | 2.2KW | 　 | ||||
| Power of hydraulic pressure | 　 | 　 | 7.5KW | 　 | 11KW | 　 | ||
| Power of cooling system | 　 | 　 | 3KW | 　 | 3KW | 　 | ||
| Air consumption | 　 | 　 | 　 | 6kgs,0.5m3/hr | 6kgs,0.5m3/hr | |||
| Power,Voltage | 　 | 　 | 　 | 380V,50HZ | 380V,50HZ | |||
| Weight | 　 | 　 | 　 | 　 | 2500kg | 　 | 3800kg | 　 |
| Size | 　 | 　 | 　 | 　 | 2700×1150×2100mm | 3500×1400×1900mm | ||
