cable puller,Cable Drum Winch - 001

cable puller,Cable Drum Winch
Powered winches are the construction tools of erecting electric circuits of high pressure electric transmission in the sky and laying eletrical cables underground. It apply to hoisting mechanical equipments and erecting pole pylon. According to different power, include Petrol Engine Powered Winches and Diesel Powered Winches.
Application:
It is used for tower erection, stringing in electric power line construction.
Features:
Speedy and Efficient;
Safe and Reliable;
Compact structure;
Small volume;
Light in weight;
Features
Engine can start by switch.
Easy operating.
The brake can hold heavy materials when working stopped.
Double frame can reduce the machine load from engine vibration.
Transmission convert to shift the speed is very easy and smooth.
Petrol Engine Powered Winches
Cat. No. QY012-3 QY012-5 QY012-8
Model JMC-3T JMC-5T JMC-8T
Petrol Engine GX160 GX390 GX450
Engine Power (Hp) 5 6 9
Rotation Speed（rpm） 3***0
Pull (kN)/ linespeed (m/min) I 18/15 I 28/18 I 50/20
Ⅱ 30/8 Ⅱ 50/9 II 80/10
Reverse I 15/13.6 Reverse I 28/16 Reverse I 50/18
Reverse II 30/7 Reverse II 50/8 Reverse II 80/9
Dimensions  (mm) 1200×650×700 1350×750×700 1500×900×700
Weight（Kg） 95 135 195
Diesel Powered Winches
Cat. No. HT0712-3 HT0712-5 HT0712-8
Model JMQ-3T JMQ-5T JMQ-8T
Engine 170F R180 R185
Engine Power (Hp) 3.8 8 9
Rotation Speed（rpm） 2***0
Pull (kN)/ linespeed (m/min) I 15/15 I 28/18 I 50/20
Ⅱ 30/8 Ⅱ 50/9 II 80/10
Reverse I 15/13.6 Reverse I 28/16 Reverse I 50/18
Reverse II 30/7 Reverse II 50/8 Reverse II 80/9
Dimensions  (mm) 1200×650×700 1350×750×700 1500×900×700
Weight（Kg） 120 165 225
Electric Powered Winches
Cat. No. HT0713-3 HT0713-5
Model DJMQ-3T DJMQ-5T
Motor
Motor Power(K W) 3KW 4KW
Rotation Speed（rpm） 2600 2600
Pull (kN)/ linespeed (m/min) I 30/4 I 50/3
Ⅱ 15/7 Ⅱ 30/4
Reverse I 30/3 Reverse I 50/3
Dimensions  (mm) 1050×600×600 1200×650×700
Weight（Kg） 75 110
