aluminum honeycomb panel

Detail description: Front side: Aluminum roll coated with PVDF or polyester Core: Alumminum honeycomb Rear side: Aluminum coated with polyester

Specifications: Aluminum sheet thickness: A) 0.50 x 0.50mm B) 0.40 x 0.40mm C) 0.30 x 0.30mm D) 0.21 x 0.21mm E) 0.15 x 0.15mm Panel thickness: 2mm~15mm

Dimensions: A)

Width: 1220mm, 1250mm, 1550mm B)

Length: 2440mm, or as customers' request Standard size (width x length x thickness): A) 1220 x 2440 x 3mm B) 1220 x 2440 x 4mm C) 1220 x 2440 x 5mm D) 1220 x 2440 x 6mm Normal color: 10 kinds Non-standard sizes and special colors are available according to customers' requests Characteristics: 1. Excellent fireproof property 2. Super peeling strength 3. Perfect cold resistance performance 4. Excellent surface flatness and smoothness 5. Superior weather, corrosion, pollutant resistance 6. Even coating, various colors 7. Superior impact resistance 8. Lightweight and easy to process 9. Easy to maintain

Applications: 1. Gas piping, cables, building materials, etc (this product fills a gap in the domestic construction materials field, with performance indexes superior to panels manufactured overseas) 2. Curtain wall decoration for buildings where security is important,as airports, hospitals and research centers 3. Curtain wallboards for outside walls of normal buildings 4. Renovations for old buildings and movable houses 5. Reformation and decoration for indoor walls, ceilings, bathrooms, kitchens and balconies 6. Facades 7. Billboards, exhibition desks and notice boards 8. Wallboards and ceilings for tunnels 9. Materials for industrial application, car and ship bodies
