ZigBeeUSB Interface Module

YT-101 ZigBee USB interface module provides an USB interface that conforms to IEEE802.15.4 protocol standard. It integrates the TI CC2430 chip. The USB interface module can be connected to the mainframe computer quickly and easily and it is completely compatible with ZigBee protocol.

Meanwhile, it enables communications with routers, coordinators and terminals in ZigBee network. Technical parameter Broadband 2.4~ 2.4835GHz

Channel capacity 16

Emission intensity -25dBm~0dBm

Communication distance 50 m

Working voltage USB standard 5V DC

Working temperature -10~50°C

Working humidity Max 95%RH

Size 54.5mm x 22.2mm x 9.4mm

Development tool of the YT-101 software includes a convenient application interface providing for software developer and thus you do not need to get familiar with wireless technology and so as to the development of USB driver. Main features ZigBee device type: Combined Interface (0x0007) is a Router.

Completely compatible with IEEE 802.15.4; Use 2.4GHz ISM frequency band and there are totally 16 channels. USB powered Serial communication interface (virtual serial port in Windows system); Integrated PCB on-board antenna; Communication distance: 50 meters Standard USB “key ring” size; Simple operation and setup.
