ZQ-A4 Bottle making machine
Specifications
- Brand
- LONGWAY
- Origin
- China (Mainland)
ZQ-A4 Bottle making machine is a Other Plastic & Rubber Machinery product. Key specs — Brand: LONGWAY; Origin: China (Mainland).
Product Description
Main part: Pneumatic part Valve SMC Cylinder Electric part PLC LG Mitsubishi Operating system LG /HITECH Relay OMRON Infrared thermometer America raytek Note All of the electrical components adopts CE,UL,CCC approved international advanced high-tech product.
Main parameter: Productivity Depend on bottle design 4500-5500PCS/H Product type Body diameter 20mm-100mm Height 50mm-350mm Neck diameter 15mm-38mm Mold Cavity 6cavities Mold thick 240mm Mold volume 240*320*760mm Main machine power Electrical source power 380v 3Phase /220v 3Phase 50/60HZ Rated Power 65kw Really use power 18kw Air source LP air compressor 2.0m3/min 1.0MPa 1set HP air compressor 3.2m3/min 3.0MPa 2sets 1set Air dryer 3.0m3/min 3.0MPa 1set Cooling water Cooling water 5HP Size L*W*H 2000*3200*1800mm Weight 5200kg
