ZP40-9 rotary tablet press-chinatabletpress

We can manufacture the tablet press machine as you request.This tablet press, the latest product,is widely used in chemical, food, veterinary frugs area. The machine can press all kinds of granular materials into a variety of shapes. The machine is packaged by stainless steel. The pressing room uses a new fully enclosed structure of plexiglass.

It is bright and perspective, of good appearance and low noise, easy to operate and maintenance .Punching can be assembly and disassembly typed, and only needs to change the nail and mode.We can manufacture the tablet press machine as you request.Dies 9sets

Max pressure 400Kn

Dia of Tablet 60mm

Depth of Fill 43mm

Thickness of Tablet 22mm

Turret Speed 10r/min

Production Capacity 5400pcs/h

motor 380v/50hz

Overall Size 900×900×2200 mm

Net Weight 2800kg
