Yamaha F50TLR outboard

Year:

Current

Model:

F50 HP

Model Number:

F50TLR

Series:

Four Stroke Midrange

HP:

50

Engine Type:

4 Cylinder

Displacement:

60.8 ci (996 cc)

Borex Stroke:

65 x 75 mm (2.56 x 2.95in)

Prop Shaft Horsepower:

50 5500 RPM

Compression Ratio:

9.5

RPM Range:

5000-6000

Fuel Induction System:

EFI (SOHC)

Fuel Type:

Unleaded gasoline (minimum pump octane 87)

Exhaust:

Thru prop

Ignition System:

TCI Micro Computer

CARB Rating:

3-Star

Alternator Outputat WOT:

17A

Starting System:

Electric

Lubrication:

Wet Sump

Oil Capacity:

2.6 quarts

Recommended Engine Oil:

Yamalube 4M

Gear Ratio:

1.85

Control Type:

Remote

Trolling Throttle Adjustment:

50 RPM increments (600 - 1000 RPM range) via Command Link System

Cooling:

Water, Thermostatic Control

Weight:

237 lb (108 kg)

Gear Shift:

F-N-R

Command Link System:

Optional Equipment

Enhanced Ultimate Corrosion Protection System UCP:

Standard Feature

Power Trim and Tilt:

Yes

Shaft Length:

20 inch

Gearcase Rotation:

Right Hand (Standard)

Propeller:

Optional Equipment

Tiller Handle Kit:

Optional

Freshwater Flush:

Yes
