YDN-D101 Decoder

YDN-D101 is a professional digital signal processor, which specially designed for the content providers, broadcasters, telecom, cable and ground operators, also the perfect platform for digital signal decoding and TS stream processing. This equipment has 1RU configuration design, further more, it assembles the decoder, TS stream descrambler and multiplexer, broadband IP stream processor, QAM/COFDM modulator with various input interface. And widely used in all kinds of digital television network, that could meet the special needs of various operators.

Features

â—† Compact 1RU configuration design, completely fulfill MPEG-2() and DVB Standard

â—† Multiple optional input signals, such as: TS,QPSK,QAM,COFDM,DS3,IP, etc.

â—† DS3 module could compatible with Bacro, Huawei, Lucent, etc

â—† Dual PCMCIA DVB-CI interface,support single/multiple decodeing,double-card decoding and BISS 1/E.

â—† Support the conditions of Conax,Cryptoworks,Irdeto,NDS,Mediaguard,SECA,Viaccess,DVN,

STV, etc.

Receiving System

â—† 1 channel ASI code stream input interface.

â—† 2×2 channels ASI code stream output or 1×2 channel ASI and 1×2 SDI output interface.

â—† Built in PID filtering PSI/SI editing ¼¬/

â—† support TS over IP 100Mbit/s or GbE input/output

â—† Support SDI output (embedded audio)

â—† Support TELETEXT VBI output

â—† Support EBU SUBTITLE and DVB SUBTITLE
â—† ETHERNET network management interface, support SNMP, software upgrades can be through the network interface
