YAMAHA MOTORCYCLE 1100cc

Engine
Type 998cc, liquid-cooled 4-stroke DOHC 16 valves (titanium intake valves)

Bore x Stroke 78.0mm X 52.2mm

Compression Ratio 12.7:1

Fuel Delivery Fuel Injection with YCC-T and YCC-I

Ignition TCI: Transistor Controlled Ignition

Transmission 6-speed w/multiplate slipper clutch

Final Drive #530 O-ring chain

Chassis
Suspension/Front 43mm inverted fork; fully adjustable, 4.7-in travel

Suspension/Rear Single shock w/piggyback reservoir; 4-way adjustable, 4.7-in travel

Brakes/Front Dual 310mm disc; radial-mount forged 6-piston calipers

Brakes/Rear 220mm disc; single-piston caliper

Tires/Front 120/70ZR17

Tires/Rear 190/55ZR17

Dimensions
Length 81.1 in

Width 28.1 in

Height 44.5 in

Seat Height 32.8 in

Wheelbase 55.7 in

Rake (Caster Angle) 24.0°

Trail 4.0 in

Fuel Capacity 4.8 gal

Fuel Economy** 33 mpg

Wet Weight 454 lb

Other
Primary Reduction Ratio 65/43 (1.512)

Secondary Reduction Ratio 47/17 (2.765)

Gear Ratio - 1st Gear 38/15 (2.533)

Gear Ratio - 2nd Gear 33/16 (2.063)

Gear Ratio - 3rd Gear 37/21 (1.762)

Gear Ratio - 4th Gear 35/23 (1.522)

Gear Ratio - 5th Gear 30/22 (1.364)

Gear Ratio - 6th Gear 33/26 (1.269)

Warranty 1 Year (Limited Factory Warranty)
