YAG Laser Marking Machine for Sanitary ware

&nbsp Semiconductor pump laser marking system output beam quality closer and more suitable for the ideal mode in fine processing, minimum characters' inch of 0.2 mm, laser marker accuracy reached a new orders of magnitude.

Responding speed Semiconductor pump laser marking system using optical devices, super fine the galvanometer speed than traditional laser system. Adopts low energy consumption Semiconductor laser marking system application efficiency, semiconductor laser matrix conversion efficiency greatly improved.

Adopts high reliability Semiconductor laser marking system integration system of high, do not need To high voltage power supply, high-voltage device, greatly guarantee system reliability.

Responding to small volume Highly integrated control system for customers better use of factory space. &nbsp Applicable materials and industry Widely used in mobile phone keypad, plastic buttons, electronic components, light integrated circuit (IC), electrical appliances, communication products, signage, sanitary ware, hardware tools, precision instrument, fittings, jewellery, watches, glasses, auto parts, cutting tool, decorative clasp locks, cookers, stainless steel products, PVC pipe, medical equipment, etc.

Applicable materials include: can in any metal (containing rare metal), engineering plastic, electroplating materials, coating material, coating materials, plastic, rubber, epoxy resin, ceramics, materials, high resolution, marks the very beautiful image. &nbsp &nbsp &nbsp &nbsp &nbsp &nbsp &nbsp Technical Parameters Model Number

HW YAG-ZJ50-II

Max.Output Power

50W

Laser Wavelength

1064nm

Electric Power Demand

220V/Single Phase /50HZ/15A

Standard Marking Scope

100mmX100mm(optional)

Width

0.015mm

Machine power

1.5KW

Repetion Precision

±0.0025mm

Marking Speed

≤7000mm/s

Host system size

1220mm*650mm*1200mm

Cooling System

Water Cooling
