XLPE insulated control cable

Type:
PVC insulated, PVC out sheath control cable: From 2x0.75 to 2x40. Till 61x0.75mm2 to 61x2.5mm2 ...
PE insulated, PE out sheath control cable
PE insulated, PVC out sheath control cable
PE insulated,... PVC out sheath, copper wire braided shield control cable

1. Scope of Application

The control cable are suitable for the wiring of electrical controlling equipments and instrument,monitoring and controlling return circuit,electrical protection and measurement in power distribution unit under thecircumstance that the rated voltage is up to 450/750V AC.

2.Service Conditions

(1)The long-time working temperature of conductor of PVC insulated cable is 70oC

The long-time working temperature of conductor of XLPE insulated cable is 90oC

(2)The temperature for laying the cables can not be lower than 0oC.Permissible bending radius(r):unarmoured cable:r≥6D;(D: outer diameterof the cable);armoured or copper-tape screened cable:r≥12D;shieldedflexible cable:r≥6D
