Wire Mesh Reinforcement

AS/N2S 4671:2001 Australia/New Zealand fabric standard Types (mm) (mm) (mm) WIPE DIAMETER WIRES NUMBER PITCH OF WIRES SHEET DIMENSION (㎡) 　 　 (㎏) (㎏/㎡) MESH longitudinal cross longitudinal cross longitudinal cross Width Length SHEET Edge wires SHEET 　 TYDE LONG CROSS LONG CROSS LONG CROSS WIDTH LENGTH AREA 　 　 WEIGHT 　 Sqaure Mesh SL52 4.77 4.77 10 30 200 200 2400 6000 14.40 　 　 20.000 1.4000 SL62 6.00 6 10 30 200 200 2400 6000 14.40 4x4.24＠100 33.000 2.292 SL72 6.75 6.75 10 30 200 200 2400 6000 14.40 4x4.77＠100 41.000 2.778 SL81 7.60 7.60 25 60 100 100 2400 6000 14.40 0 　 105.000 7.100 SL82 7.6 7.6 10 30 200 200 2400 6000 14.40 4X5.37＠100 52.000 3.611 SL92 8.6 8.6 10 30 200 200 2400 6000 14.40 4x6.00 66.000 4.514 SL102 9.5 9.5 10 30 200 200 2400 6000 14.40 4X6.75＠100 80.000 5.556 SL63 6 6 6 30 300 300 2300 6000 13.80 4X4.00＠100 21.000 1.594 SL53 4.77 4.77 6 20 300 300 2300 6000 13.80 4X4.00＠100 15.000 1.000
