Wedge Wire Well Screen

1.Wedge Wire Well Screen consist of V-shape or wedge shape profile wire and the longitudinal support rods.

2.Theconsecutive slot of Wedge Wire Well Screen have more open area, and it can reduce the speed of the water entering to avoid the sand entering the screen under the great pressure, so it can filter sand better.

intersecting point of these wires is fusion welded, so it has sturdy construction and good mechanical property.

Specifications:

1. Wedge Wire Well Screen Materials: stainless steel and low carbon steel, such as 304 302 304L 316 316L Q235, and they can be made according to the customers requirement.

2.Diameter:33-600mm (1-20inch)

3. Wedge Wire Well Screen Slot:0.05,0.1,0.2,0.5,0.75,1,1.5,2mm

4.Length:1-10m(5.8m for the 20ft container)

5.Standard: ISO, API

6.Connection: Welding, Thread (STC,LTC,BTC),Flange

7.Supply capacity:6800m/monthcontact: xxhdzg16 at live dot cn

8. First class technology, High quality, Competitive price, Fast delivery

Meanwhile, the specification of Wedge Wire Well Screencan change according to the real condition of the earth.

If you are interested in Wedge Wire Well Screen, please contact us for more information.
