Volumetric water meter is a Auto Meter product. Key specs — Origin: China.
Product Description
Measuring the volume of cold potable water passing through the pipeline
Quality:
•Optimum accuracy and performance at all times,in any position;
•Revolutionary grooved piston for improved,durability and performance;
•Durable tamperproof construction;
•Volumetric measurement by rotary piston method,wet mechanism,high accuracy,liquid-sealed horizontal and vertical type is available.
•Model LXH-15B,20B is the world’s favourite domestic water meter,with over 50 million already in service in over 100 countries,and offers accuracy,long life,low maintenance and tamperproof operation.Available in sizes 15mm and 20mm,it offer unrivaled performance to ISO4064 Class C or D.
Working condition:
temperature:≤40℃
Pressure: ≤1Mpa
•Maximum permissible error In the lower zone from qmin inclusive up to but excluding qt is ±5%
•In the upper zone from qt inclusive up to and including qs is ±2%
ACCESSORIES
•With every meter, there will be one set couplings optional: 2pcs tube, 2pcs nut and 2pcs gasket.
NOTE
•Technical data conform to International Standard ISO4064
