Video borescope PBD2

FLEXIBLE COLOR VIDEO BORESCOPE The high-quality Flexible Color Video borescope is supplied as a complete, fully portable system specially designed for search professionals to use in areas that are difficult to access such as inside tube,tanks and behind concealed panels.

The Flexible Color Video borescope has diameter 5-8mm, lengh 1-3meter, oil/waterproof, illuminated crush-resistant Endoflex vertebrae core, and tough polymer outer with stainless covered tip bending section. The borescopes has 2-way remote end tip with >120degreeleft/right articulation.

A full color video camera ship is connected to the tip, and the image can be viewed on the color LCD monitor supplied. WS-PBD2-series borescope are new video borescope. It includes video camera,LCD display, insert tube, light source,software,battery and so on. It is powered by the Rechargeable battery, you can adjust the brightness.

The consecutive working time is 8 hours.

SPECIFICATION Sensor:1/10" video system Image:Color Diameter:4.5mm,5mm,6mm,7mm,8mm (optional) Head of tube:5mm, 6mm, 7mm, 8mm Working length:1M,2M, 3M Angle of viewing:55 degreeor 100 degree Bending ways:2 ways(120 degree/120 degree) Insert tube:flexible Monitor:3.5" TFT LCD Display corner:0 degree- 90 degree Battery:Li-ion Light Source:LED White Balance:Manual or auto Temperature:0 degree --60 degree Humidity:5%_80% Causticity:Yes Waterproof:Yes WWORKING PLACE Varieties of machinery and equipment\engine inspection.

Transport (car\plane\ship) inspection. Dangerous environment inspection------somewhere has hazardous gas and liquid.
